Ji'an city Qing Feng Filter Equipment Material CO.,Ltd

Products

Home > Products > Micropore Filter Cartridge > PP Melt Blown Filter Cartridge > PP Sediment Melt Blown Pleated Filter Cartridge

PP Sediment Melt Blown Pleated Filter Cartridge
PP Sediment Melt Blown Pleated Filter Cartridge
PP Sediment Melt Blown Pleated Filter Cartridge
PP Sediment Melt Blown Pleated Filter Cartridge
PP Sediment Melt Blown Pleated Filter Cartridge

PP Sediment Melt Blown Pleated Filter Cartridge

Payment Type: L/C,T/T,D/P,Paypal,Western Union
Incoterm: FOB,CFR,CIF,EXW,FCA,CPT,CIP
Min. Order: 25 Piece/Pieces
Delivery Time: 10 Days

Contact Now Add to Basket

Download:

  • Basic Info
  • Product Description
  • Email
Basic Info

Model No.: PP Melt Blown filter cartridge

Type: PP Filter

Filtration Grade: PRE Filter

Filter Media: PP Melt Blown

Pore Size: 1.0-100um

Length: 10" ~40"

End Connection: DOE/222/226

Outer Diameter: 60~130mm

Inner Diameter: 28mm,30mm

Normal Operating Temperature: ≤50ºC

Max.Operating Temperature: 80ºC(△P≤0.10Mpa)

PH: 1-13

Additional Info

Packaging: Carton Packing

Productivity: 100000PCS/Year

Brand: QingFeng,OEM

Transportation: Ocean,Land,Air

Place of Origin: china

Supply Ability: 100000PCS/Year

Certificate: SGS and ISO9001

HS Code: 8421999090

Port: Shanghai,Shenzhen

Product Description


PP Melt-blown Filter Cartridge
PP Melt Blown Cartridge Filter Main Features:

1.Melt Blown PP Cartridge with One step melt-blown forming with polyproplene;
2,Melt Blown PP Cartridge with High flow rates;
3,Excellent ability of dirty-holding ;
4,Low cost ,economic choice for all prefiltration ;
5,Easy installation ,replacement and maintenace.

Specifications & Technical data

Material Membrane: PP fibre
Core: polypropylene O ring/Gasket: Silicone/Viton/TEV/EPDM
Specifications: Pore size (um): 0.5-100
Outer Diameter(OD): 60/62mm (can be decided by client)
Length (inch): 10, 20, 30, 40
Endcaps: DOE, SOE (code2, code3, code7, code8)
Technical data: Normal working temperature: 50 ºC/ 108ºF
Max. working temperature: 90 ºC/ 194ºF (P≤1.0 bar)
Max. differential pressure: 4.2 bar
PH value: 1-13
Sterilization method: Nil
Test: strict test before packing

Applications: (mainly for prefiltration or coarse filtration)

1,Prefiltration for water purification;
2,Coarse filtration for all kinds of beverage and wine;
3,Prefiltration for microelectronic and medicine industries;
4,Cleaning for sewage processing

Quality Assurance:

1,ISO9001:2000 certified company;
2,Pharmaceutical grade material;
3,Pharmaceutical grade workshops; (according to GMP criterion);
4,Strick test before packing

5 Micron Pp Melt Blown Filter Cartridge for Water Treatment
1.Product Describtion:
PP melt blown filter cartridge 10" 20" 30" 40"
Length 254mm 508mm 762mm 1016mm
Flow rate (t/h) 0.5 1 1.5 2
Specification Melt blown pp filter cartridge
Precision (um) 0.5-100
Outer diameter(mm) 62-65mm
Inner diameter 28-30mm
Max temperature PP(90°C), TZM(120°C)
Remark Filter precision, length can be optional
PP Melt Blown Cartridge filterMelt Blown PP CartridgeMelt Blown PP Spun
PP Sediment Melt Blown Pleated Filter CartridgePP Sediment Melt Blown Pleated Filter Cartridge
PP Sediment Melt Blown Pleated Filter Cartridge PP Melt-blown Filter Cartridge
Main Features:

1,One step melt-blown forming with polyproplene;
2,High flow rates;
3,Excellent ability of dirty-holding ;
4,Low cost ,economic choice for all prefiltration ;
5,Easy installation ,replacement and maintenace.

Specifications & Technical data

Material Membrane: PP fibre
Core: polypropylene O ring/Gasket: Silicone/Viton/TEV/EPDM
Specifications: Pore size (um): 0.5-100
Outer Diameter(OD): 60/62mm (can be decided by client)
Length (inch): 10, 20, 30, 40
Endcaps: DOE, SOE (code2, code3, code7, code8)
Technical data: Normal working temperature: 50 ºC/ 108ºF
Max. working temperature: 90 ºC/ 194ºF (P≤1.0 bar)
Max. differential pressure: 4.2 bar
PH value: 1-13
Sterilization method: Nil
Test: strict test before packing

Applications: (mainly for prefiltration or coarse filtration)

1,Prefiltration for water purification;
2,Coarse filtration for all kinds of beverage and wine;
3,Prefiltration for microelectronic and medicine industries;
4,Cleaning for sewage processing

Quality Assurance:

1,ISO9001:2000 certified company;
2,Pharmaceutical grade material;
3,Pharmaceutical grade workshops; (according to GMP criterion);
4,Strick test before packing

5 Micron PP Melt Blown Filter Cartridge for Water treatment
1.Product Describtion:
PP melt blown filter cartridge 10" 20" 30" 40"
Length 254mm 508mm 762mm 1016mm
Flow rate (t/h) 0.5 1 1.5 2
Specification Melt blown pp filter cartridge
Precision (um) 0.5-100
Outer diameter(mm) 62-65mm
Inner diameter 28-30mm
Max temperature PP(90°C), TZM(120°C)
Remark Filter precision, length can be optional
PP Sediment Melt Blown Pleated Filter CartridgePP Sediment Melt Blown Pleated Filter CartridgePP Sediment Melt Blown Pleated Filter Cartridge
PP Sediment Melt Blown Pleated Filter CartridgePP Sediment Melt Blown Pleated Filter Cartridge
PP Sediment Melt Blown Pleated Filter Cartridge

Looking for ideal Melt Blown Pp Spun Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the PP Melt Blown Cartridge Filter are quality guaranteed. We are China Origin Factory of Melt Blown PP Cartridge. If you have any question, please feel free to contact us.

Product Categories : Micropore Filter Cartridge > PP Melt Blown Filter Cartridge
